# 6 Zone one-way page control # All call # Background music input, automatically mutes in zone being paged # Page override for special priority announcements # Features are programmable per zone # Built-in tone generator for night ringing, time clock tone, doorbell # Accepts pulse and tone dial # Battery back-up input # Built-in power # UL listed # To interface with analog extension or Centrex line add the VC-V-9970 # Access: page port on selected telephone systems, PBX loop start or ground-start trunk port, electronic or 1A2 line key (line card required), or dedicated single line phone set # Input impedance: 600 ohm # Music source impedance: 4 to 600 ohm # Music input level: -10dBm nominal # DC output: -24 Vdc @ 1.5A # Power requirements: 230 Vac/1A or 120 Vac/2A # Weight: 10lbs # Dimensions: 10.9"H x 13"W x 2.7"D # VALCOM POWER UNITS (+30)
