vip-801A

SKU: VIP-801A
Brand: Valcom
Valcom VIP-801A Enhanced Network Audio Port VIP-801A The VIP801 Networked Page Zone Extender enables voice access to a single zone of one-way paging over an IP-based LAN/WAN., UPC: 799111011509
List Price: $660.00
Price: $345.00
You Save: $315.00 (48%)
vip-801A
vip-801A
Product Details
Enhanced Network Audio Port

The VIP-801A Networked Page Zone Extender enables voice access to a single zone of one-way paging over an IP-based LAN/WAN. This allows page zone extension anywhere on the network.
Features:
  • 1 Audio output
  • 2 Programmable form C relay closures
  • No server required
  • 1 to 11 Digit dial plans
  • Easy windows based setup
  • AUX Audio input
  • Audio Indication
  • Door Unlocking
Specifications:
  • VoIP Remote handset paging system access to networked VIP-800 audio adapters
  • Point to point or multi-point communication to other telephones and PagePac station doorphone call in stations
  • Ringdown circuit
  • Information phones - using ringdown with 2500 set
Input:
  • Analog device line interface-
  • 600 Ohm Input Impedance
  • VOX and Contact closure input
Output
  • Analog output interface
  • Less than 50 Ohms output impedance
  • Frequency Response: 200 Hz – 3400 Hz
  • Relay closure available
