Multipath One Way Paging Sys, 96 Zones, Exp up to 192 Zones



MultiPath Communications System is a high-performance microprocessor controlled communications system designed for the needs of large facilities. It combines the features of an electronic telephone system with the capabilities of a sound and program distribution system, and includes emergency all call paging and alarm functions.

Features:

• Supports up to 4 administrative ports for communications between administrators and zones
• Each administrative port can be connected to a single line telephone, key system, or PBX as required for unlimited answering positions
• Includes eight audio paths to simultaneously allow any combination of administrative phone and zone communications, paging, scheduled tones, and distribution of program material
• Each zone is equipped with one or more loudspeakers to receive scheduled tones, program material, such as background music, emergency tones, page announcements and intercom
• Equipped with call in switches, and supports both one-way and talkback speakers and horns to provide audio to production areas, hallways, outside locations, individual offices or classrooms
• System configuration is easily changed or upgraded
• (8) User defined relay outputs
• (6) User defined switch inputs
• (3) Auxiliary music inputs
• (1) Microphone input
• (1) BD-9 serial port for administration
• (1) Ethernet port for network administration
• (1) Real Time Clock
• (1) 4 telephone interface circuits
• (1) Speaker Outputs (quantity varies from 24 to 360)
• (1) Call Button Input (talkback systems) or Zone Relay Outputs (one way) per zone
• (1) 8 Time Schedules
• (1) Numerous Built In Tones for Alerts

Package Content:

• V-PR24 Includes:
  • (1)V-CPU4 System CPU Board:
    • Provides internal common control
    • Provides an access point for external communication functions
    • Supports up to 15 feature cards and 360 station ports
  • (1)V-STX 24 Point One-Way Paging Expansion Card:
    • 24 Line Level Speaker Outputs
    • Allows voice and tone annunciation
    • Relay Output Per Zone
  • (1)V-MCRK 9 Position Rack Mount and Power Harness:
    • Fits into standard 19" rack
    • Provides card slots for up to 9 feature cards/V-CPU4
    • Power harness included
  • (1)V-MPT Windows Programming Tool:
    • Software to program all system database information and hardware configurations
  • (1)V-C6124P 6 AMP Wall Mount Power Supply:
    • Powers up to 3 features cards/V-CPU4
    • 6 amp, 24 Vdc, Filtered and Regulated
    • Wall mount
  • (1)VC40R-4 4 Position Back Plane Cable:
    • Connects up to 4 feature cards
    • Provides all audio and data information to feature cards
• V-PR48 Includes:
  • (1)V-CPU4 System CPU Board
  • (2)V-STX 24 Point One-Way Paging Expansion Card
  • (1)V-MCRK 9 Position Rack Mount and Power Harness
  • (1)V-MPT Windows Programming Tool
  • (1)V-C6124P 6 AMP Wall Mount Power Supply
  • (1)VC40R-4 4 Position Back Plane Cable
• V-PR72 Includes:
  • (1)V-CPU4 System CPU Board
  • (3)V-STX 24 Point One-Way Paging Expansion Card
  • (1)V-MCRK 9 Position Rack Mount and Power Harness
  • (1)V-MPT Windows Programming Tool
  • (2)V-C6124P 6 AMP Wall Mount Power Supply
  • (1)VC40R-4 4 Position Back Plane Cable
• V-PR96 Includes:
  • (1)V-CPU4 System CPU Board
  • (4)V-STX 24 Point One-Way Paging Expansion Card
  • (1)V-MCRK 9 Position Rack Mount and Power Harness
  • (1)V-MPT Windows Programming Tool
  • (2)V-C6124P 6 AMP Wall Mount Power Supply
  • (1)VC40R-9T 4 Position Back Plane Cable:
    • Connects up to 9 feature cards
    • Provides all audio and data information to feature cards
    • Includes backplane terminator
