The Extreme Networks Summit X440 series switches extend the intelligence and resiliency of the ExtremeXOS network operating system to the converged access edge, enabling fine grained Quality of Service (QoS), stacking, high availability features and identity aware security in a compact, cost effective switch. Standards-based PoE/PoE+ support (802.3af / 802.3at) allows the Summit X440 series to support the large-scale rollout of converged network devices such as IP telephones, wireless access points as well as physical security devices such as video cameras.
| Product Name | Summit X440-48P |
| Product Type | Ethernet Switch |
| Manageable | Yes |
| Compatible Rack Unit | 1U |
| Ethernet Technology | Gigabit Ethernet |
| Number of Total Expansion Slots | 4 |
| Number of PoE+ (RJ-45) Ports | 48 |
| Stack Port | Yes |
| Media Type Supported | Twisted Pair |
| Total Number of Network Ports | 44 |
| PoE (RJ-45) Port | Yes |
| Height | 1.7" |
| Width | 17.4" |
| Depth | 10.0" |
| Expansion Slot Type | SFP |
| Product Series | X440 |
| Form Factor | Rack-mountable |
| Product Model | X440-48p |
| Network Technology | 10/100/1000Base-T |
| Product Line | Summit |
| Layer Supported | 2 |
| Standard Memory | 512 MB |
| Token Ring Port | No |
| LRE Port | No |
| Redundant Power Supply | Yes |
| USB | No |
| Number of SFP Slots | 4 |
| Modular | No |
| Management Port | Yes |
| Uplink Port | No |
| Number of Stack Ports | 2 |
| Bypass | No |
| Shared SFP Slot | Yes |
| Memory Technology | DRAM |
| Certifications & Standards | EMI/EMC Standards: - FCC CFR 47 part 15 Class A
- ICES-003 Class A
- EN 55022:2006+A1:2007 Class A
- EN 55024:A2-2003 Class A includes IEC 61000-4-2, 3, 4, 5, 6, 11
- EN 61000-3-2, 8-2006
- EN 61000-3-3 2008
- ETSI EN 300 386 v1.4.1, 2008-04
- 2004/108/EC EMC Directive
- CISPR 22: 2006 Ed 5.2, Class A
- CISPR 24:A2:2003 Class A
- IEC 61000-4-2:2008/EN 61000-4-2:2009
- IEC 61000-4-3:2008/EN 61000-4- 3:2006+A1:2008
- IEC 61000-4-4:2004 am1 ed.2./ EN 61000-4-4:2004/ A1:2010
- IEC 61000-4-5:2005 /EN 61000-4-5:2006
- IEC 61000-4-6:2008/EN 61000-4-6:2009
- IEC/EN 61000-4-11:2004
- VCCI Class A
- ACMA (C-Tick)
- CCC
- KCC Mark
Telecom Standards: - ETSI EN 300 386:2001
- ETSI EN 300 019
- NEBS Level 1
- NEBS Level 3
- MEF 9
- MEF 14
IEEE Standards: - IEEE 802.3ab
- IEEE 802.3z
- IEEE 802.3at
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.1p
- IEEE 802.1Q
Environmental Standards: - EN/ETSI 300 019-2-1 v2.1.2 - Class 1.2
- EN/ETSI 300 019-2-2 v2.1.2 - Class 2.3
- EN/ETSI 300 019-2-3 v2.1.2 - Class 3.1e
- EN/ETSI 300 753 (1997-10)
- ASTM D3580
|
| Management | |
| Flash Memory | 512 MB |
| Power Source | Power Supply |
| Product Family | Summit X440 |
| Mfgr Limited Warranty | Lifetime |
