SKU: 1202862L1
Brand: Adtran
Adtran NetVanta T1/FT1 Network Interface Module, UPC: 607565017247
UPC: 607565017247
List Price: $300.00
Price: $223.77
You Save: $76.23 (25%)
Add to Wishlist Add to Wishlist
1202862L1
1202862L1
Previous Item Previous Item   Next Item Next Item
Product Details
A Network Interface Module (NIM) that terminates a full or fractional T1.
  • Integrated DSU/CSU for circuit protection
  • A single RJ-48C connector for T1 connectivity
  • A single RJ-45 connector activated when an optional Dial Backup Interface Module (DIM) is installed
  • Industry-leading five-year North American warranty

Technical Specifications
  • Connector: RJ-48C
  • T1 Line Rate: 1.544 Mbps
  • FT1 Line Rate: DS0 Channelized (multiple of 64k)
  • Line Code: AMI or B8ZS
  • Framing: D4 (SF) or ESF
  • Input Signal: 0 to -36 dB (DS-1)
  • Line-Build-Out: 0, 7.5, 15, 22.5 dB, Auto
  • Timing derived from WAN or internal
