4200871L1

Our Products: Fax/Servers/Gateways > Adtran
SKU: 4200871L1
Brand: Adtran
Adtran NetVanta 3205 w/ 56k/64k NIM, UPC: 607565011221
UPC: 607565011221
List Price: $1,045.00
Price: $779.16
You Save: $265.84 (25%)
Add to Wishlist Add to Wishlist
4200871L1
4200871L1
Previous Item Previous Item   Next Item Next Item
Product Details
A Modular Access Router pre-configured with the 56/64K NIM for terminating a DDS circuit. The NetVanta 3205 includes one Ethernet LAN port, a built-in firewall for network security, QoS to priority delay sensitive traffic like VoIP, DHCP to assign IP addresses, and Network Address Translation (NAT) as well to conceal private address.
  • NetVanta 3205 bundled with a 56k/64k Network Interface Module
  • Single-slot, Single-Ethernet Modular Access Router
  • Stateful inspection firewall for network security
  • Quality of Service (QoS) for delay-sensitive traffic like Voice over IP (VoIP)
  • Comprehensive PPP dial backup scheme prevents network downtime
  • Network Address Translation (NAT) for IP Address Concealing
  • Recognizable Command Line Interface (CLI) and intuitive Web-based Graphical User Interface (GUI)
  • Self-standing desktop unit with plastic enclosure
Features and Benefits
  • Single-slot, Single-Ethernet Modular Access Router for two T1s of bandwidth
  • 1U, 19-inch rackmountable metal chassis
  • Stateful inspection firewall for network security
  • Quality of Service (QoS) for delay-sensitive traffic like Voice over IP (VoIP)
  • Standards-based routing protocols
  • Comprehensive PPP dial backup scheme prevents network downtime
  • Network Address Translation (NAT) for IP Address Concealing
  • DHCP server for assigning IP addresses
  • Recognizable Command Line Interface (CLI) to reduce learning curve
  • Intuitive Web-based Graphical User Interface (GUI) with step-by-step setup wizards
  • Industry-leading five-year North American warranty
  • NetVanta 3205 bundled with a 56k/64k Network Interface Module
Technical Specifications
  • Supports up to dual-T1s worth of bandwidth
  • Interchangeable Network Interface Modules (NIMs)
  • Stateful inspection firewall protects against Denial of Service (DoS) attacks
  • QoS with Low Latency and Weighted Fair Queuing and DiffServ marking for delay sensitive traffic like VoIP
  • PPP dial backup for disaster recovery scheme back to a PPP compliant device
  • VLAN trunking allows routing between VLANs
  • Built-in DSU/CSU protects circuit - Requires Option Module
  • Supports BGP, OSPF, RIP, static routes, and bridging
  • Network Address Translation (NAT/NAPT) conceals private IP addresses
  • NAT-compatible SIP ALG
  • Auto-sensing 10/100BaseT interface to accommodate mixed Ethernet environments
  • Command Line Interface (CLI) which mimics de facto industry standard and a user-friendly web-GUI
  • Optional DSX-1 interface available for voice connectivity to a PBX
  • Optional Analog or ISDN BRI dial backup system prevents network downtime
  • Optional VPN - 5 IPSec tunnels using DES/3DES/AES encryption
  • Optional Analog Modem module used for dial backup or remote management
  • Industry-leading five-year warranty
  • A single RJ-48S connector for DDS termination
