Splice Tray for 12 Single-Fiber Heat-Shrink Fusion Splices provides optimum physical protection for the fusion splicing method.
Features:
- Type 2S
- Fiber loop retention controls bend radius
- Positive holding action for maximum splice protection
- Accepts 60 mm single-fiber heat-shrink fusion splice protectors
- Can be used for single-mode or multimode applications
- Generous size of tray prevents induced attenuation due to fiber bending
- Base and cover made of aluminum for ruggedness and durability
- Crimpable metal tabs for buffer tube strain-relief
- Additional strain-relief points available for securing buffer tubes or pigtails to tray using cable ties
- Clear plastic cover (optional) allows for fiber visibility for inspection
- Dimensions: 11.7" (29.7 cm) x 3.9" (9.9 cm) x 0.2" (0.5 cm)
